21cfm 5hp 175 Psi Air Compressor

Specifications Color: Blue Material: Cast Iron, Aluminum, Carbon Steel Process: Painting Model: V-0.6/12.5 Compression Level: 2-Level Air Delivery: 13.6~18.7m³/h /8~11CFM    Rated Pressure: 175 PSI /1.16MPa Driving Power: 4KW(5.5HP) Pump Speed: 800RPM Cylinder Diameter: 90mm/3.54in; 65mm/2.56in          Rated Exhaust Volume: 0.6L/20.29Oz/Min Number of Cylinders: 2 Main Engine Wheel: 34cm/13.39in Pipe Interface: 3.2cm/1.26in Product Base Size(L*W): 26*14cm/ 10.24*5.51in

Key Features

Built to Last: It is mainly made of cast iron, aluminum and carbon steel through the painting process, with high strength, wear resistance, rust resistance, heat-temperature resistance, and excellent performance, to ensure long-term stable operation in a variety of harsh environments.

High Efficiency: The special valve steel that has excellent strength and toughness at high temperatures, 4kw high-power, and larger cylinder diameter design provide a large exhaust volume (20.29oz/min) and strong pressure (175psi) to improve working efficiency.

Rapid Heat Dissipation: Aluminum construction and evenly distributed cooling fins accelerate heat dissipation, ensuring stable use and extending product lifespan.

Optimized Design: The air filter effectively removes moisture and impurities from the air, protecting the product. The belt-driven design provides balancing and correction, preventing bearing displacement for smoother machine use.

Quick Installation: The integrated design, along with pre-drilled holes on the base, makes installation simple and labor-saving.

Exhaust Cover: It can regulate the pressure, prevent the internal pressure of the equipment from being too high or too low, and ensure the stable operation of the machine.

Visible Oil Level Observation Window: It can help you monitor the oil level in the machine in real-time and control the amount of oil added.

Tight-Threaded Oil Cap: It ensures a secure connection, preventing oil leakage.

Comfortable Edges: They enhance your safety and comfort during use and cleaning.





Application

It is widely used in the chemical industry, light industry, textile, food processing, health, electronics, machinery, mining, construction, scientific research, factory, home decoration, auto repair, and others.





Specifications

Color: Blue

Material: Cast Iron, Aluminum, Carbon Steel

Process: Painting

Model: V-0.6/12.5

Compression Level: 2-Level

Air Delivery: 13.6~18.7m³/h /8~11CFM

Rated Pressure: 175 PSI /1.16MPa

Driving Power: 4KW(5.5HP)

Pump Speed: 800RPM

Cylinder Diameter: 90mm/3.54in; 65mm/2.56in

Rated Exhaust Volume: 0.6L/20.29Oz/Min

Number of Cylinders: 2

Main Engine Wheel: 34cm/13.39in

Pipe Interface: 3.2cm/1.26in

Product Base Size(L*W): 26*14cm/ 10.24*5.51in



HG-WMTZXL-2615-PJ

Gross Weight: 6.75kg/14.88 lbs

Net Weight: 6.41kg/14.13 lbs

Package Size: 42*41*16cm/16.5*16.1*6.3 in

HG-WMTZXL-2615

Gross Weight: 25.37kg/55.93 lbs

Net Weight: 24.1kg/53.13 lbs

Package Size: 50.5*44*34.5cm/19.9*17.3*13.6 in



Package Included

1* Air Compressor Pump Head

1* Flywheel



Notes

• We send the air compressor pump head and the flywheel separately to protect the product from damage during transportation. Please wait patiently for all parts to arrive.
• Please carefully check whether the product model, gas supply pressure, exhaust volume per minute, rated power, installation aperture, diameter of the connection pipe at the machine head, diameter of the main machine wheel, and number of cylinders meet your needs before purchasing.
• Please note that when placing the pump head, the motor pulley and belt pulley must be in the same straight line. The more aligned, the less vibration.
• Please ensure that the air compressor is placed in a well-ventilated location to help dissipate heat and avoid performance degradation or malfunction due to overheating.
• Please tighten the screws (both base and pulley screws) when installation. Please note that the belt should be tightened after the screws are installed. If the belt is loose, move the motor. After tightening the screws, reinstall the belt.
• Please note that the new machine must be filled with oil (not included) before starting, and the oil should be added to the center of the red dot of the oil mirror. Please note that the oil should be changed in the first half month, then one and a half months, and finally two to three months.
• Please note that the rotation direction of the pump head is clockwise. If it is reversed, please adjust it in time.
• Please note that the air filter should be changed regularly. Under normal circumstances, it must be replaced within two to three months, and if the environment is bad, it must be replaced within one month.
• Please note that high temperatures are generated when the machine is running, so be careful not to burn yourself!
• Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before ordering.
